Agilent 5900

Synchronous Vertical Dual View (SVDV) ICP-OES with Dichroic Spectral Combiner. Built for fast and accurate analysis with the lowest cost per sample. Offers advanced automation and diagnostics with IntelliQuant.

• Status: Active
• Country: USA
• Elemental: Yes
• Type of measurable elements: Metals and non-metals
• Measurable isotopes/elements: Elemental coverage, including major and trace elements
• Sensitivity : -
• Dynamic range : 6–9 orders of magnitude with enhanced trace detection capabilities
• Signal stability, relative standard deviation : Long-term stability with <0.5% RSD for extended operations
• Spray chamber : Cyclonic spray chamber
• Nebulizer : Concentric or high-performance nebulizers
• Peristaltic pump : Advanced peristaltic pump with integrated diagnostics for efficient sample handling
• RF generator frequency : 27 MHz
• RF generator power : Adjustable from 700 to 1500 W in 10 W increments
• View orientation/observation/optical system : Synchronous Vertical Dual View (SVDV) for simultaneous axial and radial observation
• Detection system/detector : CCD detector
• Grating /Wavelength range : 167–785 nm with optimized echelle optics for low detection limits
• Polychromator : Compact Freeform optics with rapid purge and thermostability
• Typical resolution : <5 pm in the UV region; optimized for line-rich spectra
• Gas supply: Argon ≥99.996% purity with optimized gas usage for reduced cost per sample
• Power Requirements and Consumption : 200–240 VAC, 50/60 Hz; ~3 kVA
• Environmental requirements : Operating temperature: 15–35°C; Humidity: 20–80% (non-condensing); Exhaust flow: 2.5 m³/min
• Dimensions and Weight: 800 mm W × 740 mm D × 940 mm H; Weight: 106 kg
