Quantima

Simultaneous ICP-OES spectrometer with CCD detection. Robust design for multi-elemental analysis in complex matrices. Compact and user-friendly. For environmental, pharmaceutical, and metallurgical applications.

• Status: Active
• Country: Australia
• Elemental: Yes
• Type of measurable elements: Metals and non-metals
• Measurable isotopes/elements: Elemental analysis including trace and high-concentration levels
• Sensitivity : Sub-ppb detection limits for trace elements
• Dynamic range : -
• Signal stability, relative standard deviation : <1% RSD over long-term operation, ensuring reproducibility
• Spray chamber : Cyclonic spray chamber
• Nebulizer : Concentric nebulizer with optional ultrasonic and cross-flow configurations for specific applications
• Peristaltic pump : 3-channel peristaltic pump for sample introduction and waste removal
• RF generator frequency : 27-Dec
• RF generator power : Adjustable from 700 W to 1500 W
• View orientation/observation/optical system : Dual View system for axial and radial plasma observation
• Detection system/detector : CCD detector
• Grating /Wavelength range : 165–900 nm with Echelle spectrometer for broad spectral coverage
• Polychromator : Echelle polychromator with optimized thermal stabilization
• Typical resolution : High resolution capable of resolving closely spaced spectral lines
• Gas supply: Argon ≥99.995% purity; nitrogen for extended wavelength range below 180 nm
• Power Requirements and Consumption : 200–240 V, 50/60 Hz; ~3.5 kVA
• Environmental requirements : 15–35°C; Humidity: 20–80%
• Dimensions and Weight: 110 cm W × 80 cm D × 75 cm H; ~150 kg
