Agilent 6100 Series

Retired single quadrupole LC/MS platform with SIM and scan modes with autotune optimization. Supports various ion sources and full LC control with ChemStation software.

• Status: Discontinued
• Country: USA
• Vacuum system : Included; unspecified configuration
• Power Requirements and Consumption : 200-230 VAC 60 Hz / 200-240 VAC 50 Hz; max 2000 VA; 15 A circuit
• Environmental requirements : Temperature 15-35 °C; humidity <80% RH
• Dimensions and Weight: 35.0 × 45.0 × 63.5 cm; 63.4 kg
• Mass range : 6120B: m/z 10 to 2,000; 6130B: m/z 2 to 3,000; 6150B: m/z 2 to 1350
• Sensitivity : 6120B: 10 pg, >5000:1 RMS; 6130B: 1 pg, 500:1 RMS; 6150B: 10 pg, 1000:1 RMS
• Mass accuracy/Stability : ±0.13 u; Stability: ±0.1 u or 100 ppm per 12 h
• Scanning speed : 6120B/6130B: up to 5250 u/s; 6150B: up to 10,000 u/s
• Polarity switching : 6120B: 300 ms (30 ms optional); 6130B: 30 ms; 6150B: 20 ms
• Ion source types (LC-MS) : ESI, APCI, APPI, Multimode (ESI+APCI), Nanospray with HPLC-Chip
