Trace 1600/1610

Modular GC system with high flexibility. Offers iConnect injector and detector modules. 1610 - with multi-functional touchscreen.

• Status: Active
• Country: USA
• Column type : Capillary
• Column type : Packed
• Available detectors : Flame Ionization (FID)
• Available detectors : Thermal Conductivity (TCD)
• Available detectors : Electron Capture (ECD)
• Available detectors : Mass Spectrometry (MSD)
• Available detectors : Nitrogen-Phosphorus (NPD)
• Available detectors : Photoionization (PID)
• Available detectors : Flame Photometric (FPD)
• Available detectors : Sulfur/Nitrogen Chemiluminescence (SCD/NCD)
• Available detectors : Others
• FID details : Max Temp: 450°C, MDL: <1.2 pg C/s, Linearity: 107
• TCD details : Max Temp: 400°C, MDL: <400 pg tridecane/mL
• ECD details : Max Temp: 400°C, MDL: <4.5 fg/s lindane
• MSD details : Compatible with Thermo Scientific MS Series
• NPD details : Max Temp: 450°C, MDL: <20 fg P/s, <100 fg N/s
• PID details : Yes (optional)
• FPD details : Max Temp: 450°C, MDL: 100 fg P/s, 5 pg S/s
• Other detectors : Yes (PDD, VUV, PFPD)
• Inlet types : SSL, SSL-BKF, PTV, PTV-BKF, COC, TSI, GSV
• Injector general parameters: Max Temp: 450°C, Pressure: 0-150 psi
• Flow control : Integrated Electronic Control (IEC), HeSaver technology
• Autosampler compatibility : TriPlus RSH, TriPlus 500 Headspace, AS 1310
• Data acquisition and control: Chromeleon CDS, Xcalibur, TraceFinder
• Column oven specifications : Ambient +3°C to 450°C, Cryogenic down to -100°C
• Safety features : Over-temperature protection, Helium Saver
• Power Requirements and Consumption : 110-240 V, 2000 VA
• Environmental requirements : Ambient: 5-40°C, Humidity: 5-90%
• Dimensions and Weight: H: 45 cm, W: 44 cm, D: 67 cm, 35 kg
