2400 System

Single Quad GC-MS with SMARTsource.

• Status: Active
• Country: USA
• Available configurations: EI; EI/CI
• Analyzer type : Quadrupole MS (single)
• Scan modes : Full Scan-SIM, SIM, Full Scan
• Mass range : 1 to 1200 amu
• Ionization Modes : Electron (EI)
• Ionization Modes : Chemical Ionization (CI), Positive/Negative Chemical Ionization (PCI/NCI)
• Sensitivity : IDL 1 pg OFN S/N 1500:1
• Mass accuracy/Stability : ±0.1 m/z over 48h
• Detector type : Clarifi Electron Multiplier
• Electron energy : 10–100 eV
• Scanning speed : Up to 12,500 amu/s
• Ion source temperature : 50°C to 350°C
• Maximum column Flow Rate : Max 5 mL/min He
• Installation specifications : EI Full Scan 1 pg OFN S/N ≥1500:1
• Vacuum system : 340 L/s Turbo Pump
• Power Requirements and Consumption : 120/230V, 1000 VA
• Environmental requirements : 10°C to 30°C, 20-80% RH
• Dimensions and Weight: 48x31x65 cm, 50 kg
