ISQ 7000

Retired Single Quad GC-MS with Advanced EI and NeverVent Technology.

• Status: Discontinued
• Country: USA
• Available configurations: EI; EI/CI
• Analyzer type : Quadrupole MS (single)
• Scan modes : Full scan, SIM
• Mass range : 1.2 to 1100 amu
• Mass resolution/ Mass resolving power : Unit mass
• Ionization Modes : Electron (EI)
• Ionization Modes : Chemical Ionization (CI), Positive/Negative Chemical Ionization (PCI/NCI)
• Dynamic range : Electronic 10e9
• Sensitivity : IDL ≤1 fg OFN
• Mass accuracy/Stability : ±0.1 amu/48h
• Detector type : DynaMax XR Detection System
• Electron energy : Up to 150 eV
• Scanning speed : Up to 20,000 u/sec
• Direct inlet option : Yes
• Ion source temperature : Up to 350°C
• Installation specifications : EI SIM IDL ≤1 fg OFN, S/N ≥300:1
• Vacuum system : Turbo Pump >300 L/s
• Dimensions and Weight: 44x33x63 cm, 43 kg
