Agilent 5975C

Retired single quadrupole GC-MS with triple-Axis Detector and automated SIM/Scan.

• Status: Discontinued
• Country: USA
• Analyzer type : Quadrupole MS (single)
• Scan modes : Full scan, SIM, Synchronous SIM/Scan
• Mass range : 1.6 to 1050 amu
• Ionization Modes : Electron (EI)
• Ionization Modes : Chemical Ionization (CI), Positive/Negative Chemical Ionization (PCI/NCI)
• Dynamic range : 10⁶
• Sensitivity : EI scan: 600:1 S/N for 1 pg OFN
• Mass accuracy/Stability : Better than 0.10 amu/48h
• Detector type : Triple-Axis Detector
• Electron energy : 5–241.5 eV
• Scanning speed : Up to 12,500 amu/sec
• Ion source temperature : 150 to 350°C
• Maximum column Flow Rate : 4 mL/min (performance turbo) 3.0 mL/min (diffusion) 5.0 mL/min (standard turbo) 15.0 mL/min (performance turbo)
• Installation specifications : EI scan S/N 600:1 S/N for turbo molecular pump system and 200:1 S/N for diffusion pump system will be given by 1-μL injection of 1-pg/μL (100:1 for 6850/5975C bundle) OFN2 standard scanning from 50 to 300 u at nominal 272 u ion. PCI scan S/N (Methane) 125:1 S/N will be given by 1-μL injection of 100-pg/μL BZP3 standard scanning from 80 to 230 u at nominal 183 u ion. NCI scan S/N (Methane) 600:1 S/N will be given by 2-μL injection of 100 fg/μL OFN standard scanning from 50 to 300 u at nominal 272 u ion.
• Vacuum system : Turbomolecular Pump
• Power Requirements and Consumption : 110-240V, 50/60 Hz
• Environmental requirements : 15–35°C, 40-80% RH
• Dimensions and Weight: 88×56×50 cm, 81-96 kg
