Agilent 5973 inert

Retired inert gas single quadrupole GC-MS with inert EI and Retention Time Locking.

• Status: Discontinued
• Country: USA
• Available configurations: GC/MSD
• Analyzer type : Quadrupole MS (single)
• Scan modes : Full scan, SIM
• Mass range : 1.6 to 800 amu
• Ionization Modes : Electron (EI)
• Ionization Modes : Chemical Ionization (CI), Positive/Negative Chemical Ionization (PCI/NCI)
• Dynamic range : 10⁶
• Sensitivity : EI scan: 60:1 S/N for 1 pg OFN
• Mass accuracy/Stability : Better than 0.10 amu/48h
• Detector type : EM with replaceable horn
• Electron energy : 5–241.5 eV
• Scanning speed : 10,000 amu/sec
• Ion source temperature : 150 to 300°C
• Maximum column Flow Rate : 2 mL/min (standard turbo) 4 mL/min (performance turbo)
• Installation specifications : EI scan sensitivity 60:1 s/n for 1-pg OFN scanning from 50–300 amu at nominal m/z 272 ion PCI scan sensitivity 75:1 s/n for 100-pg BZP scanning from 80–230 amu at nominal m/z 183 ion NCI scan sensitivity 500:1 s/n for 1-pg OFN scanning from 50–300 amu at nominal m/z 272 ion
• Vacuum system : Turbomolecular Pump
• Power Requirements and Consumption : 120-240V, 50/60 Hz
• Environmental requirements : 15–35°C, 40-80% RH
• Dimensions and Weight: 88×56×50 cm, 88 kg
