AA-7000F

Flame-only AAS for routine applications with high sensitivity, double-beam optics, and compact design with advanced automation and safety features.

• Status: Active
• Country: Japan
• Elemental: Yes
• Type of measurable elements: Metals and non-metals
• Measurable isotopes/elements: -
• Signal stability, relative standard deviation : RSD <1%
• Atomizer types : Flame
• Bandwidth : 0.1, 0.2, 0.7, 1.0, 2.0 nm adjustable
• Wavelength range : 185 to 900 nm
• Wavelength accuracy : ±0.15 nm
• Background correction : Dual-method: High-speed self-reversal (SR) and Deuterium (D2)
• Optics type : Double-beam Czerny-Turner monochromator
• Burner head material : Titanium; Air-C2H2 and N2O-C2H2 configurations
• Gas management : Automatic gas flow control, including Air-C2H2 and N2O-C2H2
• Detection system : Photomultiplier tube (PMT)
• Monochromator : Aberration-corrected Czerny-Turner with automatic slit adjustment (0.2–2.0 nm)
• Lamp carousel : 6-lamp turret with dual illumination
• Photomultiplier : Standard high-sensitivity PMT
• Flame atomizer : 10 cm titanium burner; automatic height adjustment available
• Sensitivity (Flame) : 0.28 µg/mL for Copper (Cu)
• Safety features : Flame monitoring, gas leak detection, vibration sensor, automatic flame extinguishing
• Power Requirements and Consumption : 100–240 VAC, 50/60 Hz, 600 W
• Environmental requirements : Temperature: 10–35°C; Humidity: 20–80% (non-condensing)
• Dimensions and Weight: 700 mm W × 588 mm D × 714 mm H; 72 kg
