AAS3000FG Pro

Atomic Absorption Spectrophotometer AAS3000FG-Pro (Flame + Graphite Furnace Type - Pro Version); Advanced instrument for metal analysis; Extensive safety and automation features.

• Status: Active
• Country: Canada
• Elemental: Yes
• Type of measurable elements: Metals and non-metals
• Measurable isotopes/elements: -
• Signal stability, relative standard deviation : Furnace: ≤ 2.0%
• Atomizer types : Flame
• Atomizer types : Furnace
• Bandwidth : Adjustable: 0.1, 0.2, 0.4, 0.8, and 1.6 nm
• Wavelength range : 170–900 nm
• Wavelength accuracy : ±0.10 nm
• Background correction : Deuterium lamp correction up to 1.0 Abs; Self-absorption up to 2.0 Abs
• Optics type : Czerny-Turner monochromator design
• Burner head material : Corrosion-resistant material (-)
• Gas management : Automatic gas flow control and safety cut-offs
• Detection system : Photomultiplier tube (PMT)
• Monochromator : Czerny-Turner with diffraction grating (1800 grooves/mm)
• Lamp carousel : 8-lamp position with automatic rotation and alignment
• Photomultiplier : High-sensitivity type
• Flame atomizer : Automatic ignition, flame-out, and adjustable burner head
• Furnace atomizer : Graphite furnace with longitudinal heating up to 3000°C
• Furnace vision system : Includes visual monitoring system
• Furnace heating rate/max temp : Heating rate: Rapid (- in precise numbers); Maximum temperature: 3000°C
• Typical tube lifetime : -
• Sensitivity (Furnace) : Detection Limit (Cadmium): ≤ 0.4 pg
• Sensitivity (Flame) : Detection Limit (Copper): ≤ 0.002 μg/mL; Precision: ≤ 0.3%
• Safety features : Comprehensive hardware/software alarms; automatic shutdowns for gas, pressure, and ignition issues; dual air circuit breakers
• Power Requirements and Consumption : -
• Environmental requirements : -
• Dimensions and Weight: 1020 mm W × 530 mm D × 500 mm H; 85 kg
