HT7800

TEM for biological and industrial materials. Wide field observation at low magnifications. High-contrast imaging of biological ultra-thin sections

• Status: Active
• Country: Japan
• Electron gun type : LaB₆ Thermionic source
• Standard detectors : High-sensitivity CMOS camera (VELETA, Rio9, etc.)
• Optional detectors : EDX (EDAX, Bruker), CCD/CMOS cameras, STEM detector
• Cryo : Optional
• STEM : Optional
• STEM parameters: STEM detector optional
• Additional analytical capabilities (EDS/EDX ; EELS; SAED;NBD; others) : EDX, STEM, tomography, low-dose imaging
• Resolution : 0.38 nm (lattice image)
• Electron beam resolution : 0.38 nm
• Accelerating voltage : 20–120 kV
• Image parameters : TEM, SE, STEM, EDX, wide field observation
• Magnification : ×20 to ×600,000 (photo magnification), ×25 to ×800,000 (display)
• Chamber : Specimen up to 3 mm dia. standard
• Camera details : CMOS camera options: Rio9, VELETA, TEMCAM, etc.
• Stage parameters : Motorized stage with 5-axis control
• Holder Types : Single-tilt, double-tilt, high tilt, rotation, heating, cooling, cryo holders
• Sample size: 3 mm diameter (standard)
• Cooling system : Optional cooling stage available
• Vacuum system : Dry scroll and turbo pumps
• Power Requirements and Consumption : AC100 V ±10%, 1 kVA or less
• Environmental requirements : 20–25 °C, 50% RH or less
• Dimensions and Weight: Main unit: 900×1300×1600 mm, approx. 650 kg
